Current Location：Home》Product》Vane air motor

Vane air motor|pneumatic motor

Characteristics of OUXU pneumatic air motors:

1. long time work is not hot, long service life, safety and explosion-proof.

2. the rotational speed is stepless, the speed is controlled by adjusting the size of air pressure or the
size of the air intake.

3. Overload protection, no failure due to overload.

4. With high starting torque, it can be started directly with load.

5. Can Positive inversion.

Product parameters

Download：Vane air motors data

Operation Data：

Model	Gear Ratio	Maximum efficacy				Idling (R.p.m)	Starting Torque (N.m)	Maximum Torque (N.m)	Weight(Kg)
Model	Gear Ratio	Power (HP)	Torque (N.m)	Rotate Speed (R.p.m)	Air Consumption (L/min)	Idling (R.p.m)	Starting Torque (N.m)	Maximum Torque (N.m)	Basic	Vertical	Horizontal
QMY005	1:1	0.05	0.18	2000	63	3920	0.29	0.36	1.0	1.1	1.4
QMY020	1:1	0.2	0.72	2000	136	3920	1.15	1.44	2.0	2.1	2.6
	5:1		3.6	400		800	5.76	7.2
	10:1		7.2	200		400	11.52	14.4
	15:1		10.8	133		266	17.28	21.6
	20:1		14.4	100		200	23	28.8
	30:1		21.6	66		132	34.5	43.2
	40:1		28.8	50		100	46	57.6
	50:1		36	40		80	57.6	72
	60:1		43.2	33		66	69	86
QMY040	1:1	0.4	2.03	1400	420	2800	3.25	4.06	4.0	4.2	4.8
	5:1		10.15	280		560	16.24	20.3
	10:1		20.3	140		280	32.5	40.6
	20:1		40.6	70		140	64.9	81.2
	30:1		60.9	47		94	97.4	121.8
	40:1		81.2	35		70	129.9	162.4
	50:1		101.5	28		56	162.4	203
	60:1		121.8	23		46	194.8	243.6
	80:1		162.4	17.5		36	260	325
	100:1		203	14		28	325	406
QMY060	1:1	0.6	3.04	1400	630	2800	4.13	5.16	4.4	4.7	5.5
	5:1		15.2	280		560	24.32	30.4
	10:1		30.4	140		280	48.64	60.8
	20:1		60.8	70		140	97.28	121.6
	30:1		91	47		94	145.9	182
	40:1		121.6	35		70	194.56	243.2
	50:1		152	28		56	243.2	304
	60:1		182.4	23		46	291	364
	80:1		243.2	17.5		35	389.1	486.4
	100:1		304	14		28	486.4	608
QMY100	1:1	1	5.1	1400	1120	2800	8.16	10.2	6.1	6.5	7.0
	5:1		25.5	280		560	40.8	51
	10:1		51	140		280	81.6	102
	20:1		102	70		140	163.2	204
	30:1		153	47		94	244.8	306
	40:1		204	35		70	326.4	408
	50:1		255	28		56	408	510
	60:1		306	23		46	489	612
	80:1		408	17.5		35	652.8	816
	100:1		510	14		28	816	1020
QMY250	1:1	2.5	12.8	1400	2100	2800	20.48	25.6	11.6	12.0	14.2
	5:1		64	280		560	102.4	128
	10:1		128	140		280	204.8	256
	20:1		256	70		140	409.6	512
	30:1		384	47		94	614.4	768
	40:1		512	35		70	819.2	1024
	50:1		640	28		56	1024	1280
	60:1		768	23		46	1228	1536
	80:1		1024	17.5		35	1638.4	2048
	100:1		1280	14		28	2048	2560
QAM150	1:1	1.7	4.1	3000	2200	6000	6.56	8.2	4.9	5.1	5.5
	5:1		20.5	600		1200	32.8	41	GAST 4AM
	10:1		41	300		600	65.6	82
	20:1		82	150		300	131.2	164
	30:1		123	100		200	196.8	246
	40:1		164	75		150	262.4	328
	50:1		205	60		120	328	410
	60:1		246	50		100	393	492
	80:1		328	37.5		75	524.8	656
	100:1		410	30		60	656	820
QAM360	1:1	4	10	3000	3800	6000	16	20	8.5	9.2	9.5
	5:1		50	600		1200	80	100	GAST 6AM
	10:1		100	300		600	160	200
	20:1		200	150		300	320	400
	30:1		300	100		200	480	600
	40:1		400	75		150	640	800
	50:1		500	60		120	800	1000
	60:1		600	50		100	960	1200
	80:1		800	37.5		75	1280	1600
	100:1		1000	30		60	1600	2000
	120:1		1200	25		50	1920	2400
	150:1		1500	20		40	2400	3000
	200:1		2000	15		30	3200	4000
QAM480	1:1	5.25	14.4	2500	4900	3920	23	28.8	11	12	13
	5:1		72	500		1000	115.2	144	GAST 8AM
	10:1		144	250		500	230.4	288
	20:1		288	125		250	460	576
	30:1		432	83		166	691	864
	40:1		576	62.5		125	921	1152
	50:1		720	50		100	1152	1440
	60:1		864	41		82	1382	1728
	80:1		1152	31		62	1843	2304
	100:1		1440	25		50	2304	2880
	120:1		1728	20		40	2764	3456
	150:1		2160	16.6		33.2	3456	4320
	200:1		2880	12.5		25	4608	5760
QAM6	1:1	8	20.1	2800	7080	5600	32.16	40.2	18
QAM7	1:1	9.3	24	2800	8400	5600	38.4	48	23
	5:1		120	560		1120	192	240	50
	10:1		240	280		560	384	480
	20:1		480	140		280	768	960
	30:1		720	93		186	1152	1440
	40:1		960	70		140	1536	1920	60
	50:1		1200	56		112	1920	2400
	60:1		1440	46		92	2304	2880
	80:1		1920	35		70	3072	3840
	100:1		2400	28		56	3840	4800
	120:1		2880	23		46	4608	5760	94
QAM9	1	12	34.4	2500	11700	5000	55	68.8	48
QAM14	1	20	56	2500	17400	5000	89.6	112	53

Installation size：

Characteristics of OUXU pneumatic air motors:
1. long time work is not hot, long service life, safety and explosion-proof.
2. the rotational speed is stepless, the speed is controlled by adjusting the size of air pressure or the
size of the air intake.
3. Overload protection, no failure due to overload.
4. With high starting torque, it can be started directly with load.
5. Can Positive inversion.
